Magnetic Drive Acid Pumps
Magnetic Drive Acid Pump – Reliable Transfer for Corrosive Liquids
Magnetic drive acid pumps are magnetically coupled positive displacement pumps specially built for handling acids, chemicals and corrosive liquids. By using a magnetic coupling instead of a mechanical seal, they maximize sealing performance and offer superior resistance to contaminants and abrasive fluids.
Pump Type
Magnetically Coupled Centrifugal
Flow Rate Range
1 – 150 m³/h
Maximum Pressure
6 – 16 bar
Motor Power
0.37 – 15 kW
Body Material
PP / PVDF / ETFE
Sealing
Seal-less Magnetic
Operating Temperature
-10°C / +120°C
Connection Diameter
1/2” – 4”
Magnetic drive acid pumps are magnetically coupled positive displacement pumps specially built for handling acids, chemicals and corrosive liquids. By using a magnetic coupling instead of a mechanical seal, they maximize sealing performance and offer superior resistance to contaminants and abrasive fluids.
HD Marine magnetic drive acid pumps deliver high performance and durability across a wide range of uses, particularly from laboratories to production lines, from chemical plants to marine applications.
✔ High chemical resistance: Operates with harsh liquids over long periods
✔ Leak-free performance: Safe transfer thanks to the magnetic coupling
✔ Easy installation: User-friendly mounting design
✔ Long-life construction: High durability with minimal maintenance
| Pump Type | Magnetically Coupled Centrifugal |
|---|---|
| Flow Rate Range | 1 – 150 m³/h |
| Maximum Pressure | 6 – 16 bar |
| Motor Power | 0.37 – 15 kW |
| Body Material | PP / PVDF / ETFE |
| Sealing | Seal-less Magnetic |
| Operating Temperature | -10°C / +120°C |
| Connection Diameter | 1/2” – 4” |
HD Marine magnetic drive acid pumps are an effective solution particularly in:
- Chemical production plants
- Paint and solvent lines
- Water and wastewater treatment
- Acid/alkali transfer systems
- Marine and industrial processes
and in all applications requiring the safe handling of corrosive and abrasive fluids.
What is a magnetic drive acid pump?
It is a magnetically coupled positive displacement pump that provides leak-free transfer by using a magnetic drive instead of a mechanical seal.
Is it suitable for chemical liquids?
Yes, it has been developed for the transfer of acids, alkalis and chemical reaction liquids.
Why is no packing used?
Thanks to the magnetic coupling, the need for packing is reduced, providing sealing and maintenance advantages.
Where should it be used?
It is preferred in chemical plants, water treatment, paint lines and industrial processes.
